ECU Tuning Tool Buying Guide

Which ECU programming tool should you take? Ktag or Kess v2,or MPPS cable or FgTech 4 galletto v54 or KTMflash or KTMOBD or Renolink Renault ECU programmer?

Usually, it depends on what ECU list it has and connection/communication you want.Go on your reading and  know more.



IMG: The left one cable is KTMflash and the right one cable is KTMOBD cable.

KTMflash mainly works on new Siemens & gearbox, it needs to desolder ECU when reading and writing.
KTMOBD mainly read and write the Japanese ECU like Denso.

IMG: This one cable is V1.52 Renolink Renault ECU programmer via OBD.

Renolink has many features like UCH matching, airbag programming, engine ECU programming, key coding, key deletion, dashboard coding, eprom and flash reading and writing in Renault and Dacia vehicles.



Mpps v18MPPS-V18-Car-List-2016.pdf  (135.0K)

MPPS covers MAIN + TRICORE + MULTIBOOT and a wide range of controllers incl. M3.8, M5.9, ME7xx, MED9, MED17, EDC15/16/17, Delphi, Siemens, Marelli, Delco, Sagem, Trionic and many others…

Kess v2 :

 Ksuite V2.25 Kess V2 master car list

kess-v2-2.13-car-full-list-20150501.pdf  (1,745.0K)

Kess covers all major brands and protocols including Line, CAN, EDC17 and MED17 and Ford J1850.

K-tag :

Ktag firmware V7.020 ksuite V2.25 (Improved onscreen message management & Implemented reading of gearbox sensor on Magneti Marelli 8GMK ECUs)

Ksuite V2.25 free download for Ktag

ktag firmware v6.070 with ksuite v2.13 supports BDM MOTOROLA MPC5xx, and BMW Gasoline F Chassis and Mercedes W222

Fgtech galletto v54 :fgtech-car-list-truck.pdf  (84.6K)

FGTech Galletto 4 is a famous chip tuning tool for all cars, trucks, motorcycles, Marine, BDM MPCxx, BDM Boot Mode Tricore, checksum

New Version:Fgtech FW 0475 Galletto 4 Master V54 EU Version is unlocked version, support online operation, add much more and newer vehicles and ECU protocols than FW 0386, fixed all unstable problem and errors which FW 0386 had

Fgtech2 :

Fgtech 2 comes with all Cars, Trucks, Traktors and bikes. New Boot Mode System Tricore Infineon Tricore Sak TC1766, Sak TC1767 *new Infineon Tricore sak TC1792,TC1796,TC1797,TC1767. READ / WRITE New BMW by OBD2 port.

KTM OBD cable VS KTMFlash cable

KTMOBD KTMFLASH
Read and write ECU data
Read gearbox data
read the chip data
Via OBD or Disassemble ECU via OBD Most need to disassemble ECU
Read the gearbox data on these types Ford
Mazda
Honda / Acura
Nissan
Renault
Subaru
Mitsubishi
China
Toyota
Denso
FusoOthers (a little part): Kia/Hyundai, Chevrolet, SsangYong, VAG
VAG: DQ200 (0AM)
VAG: DQ200MQB/G2 (0CW)
VAG: DQ250C (02E) K-Line
VAG: DQ250E/F (02E)
VAG: DQ250MQB (0D9)
VAG: VL300/V30 (01J/0AN) K-Line
VAG: VL300/V30 (01J/0AN)
VAG: VL381 (0AW)
VAG: DQ500 (0BH/0BT)
VAG: DL501/G2 (0B5)
VAG: DQ200/MQB Boot (MICRO)
VAG: DQ200/MQB Boot (EEPROM)
VAG: DQ200G2 Boot (MICRO)
VAG: DQ200G2 Boot (EEPROM)
VAG: DQ250E/F/MQB Boot (MICRO)
VAG: DQ250E/F/MQB Boot (EEPROM)
VAG: VL300/V30 BSL (FLASH)
VAG: VL300/V30 BSL (EEPROM)
VAG: VL381 Boot (MICRO)
VAG: VL381 Boot (EEPROM)
VAG: DL501 Boot (MICRO)
VAG: DL501 Boot (EEPROM)
VAG: DL501G2 Boot (MICRO)
VAG: DL501G2 Boot (EEPROM)
Others Read the BOOT mode on Infineon;Read the encrypted ECU password for Bosch / Continental, Kia/Hyundai / Mercedes-Benz
Language English, Russian English, Russian
What you’d better know: how much different among hot ecu programmers below?
ECU tools/Communication MPPS V18 KESS v2 KTAG FgTech galletto v54
OBD2
BOOT
BDM
J-TAG
Tricore
So, KESS v2 supports obd2, boot
MPPS v18 works for obd2, Multiboot, Tricore for Marelli ECU’s
KTAG can work for bdm, j-tag, boot
FgTech Galleto v54 4 (or Fgtech 2) work no issues with obd2, bdm, j-tag, boot
Communication/

ECU tools
OBD2 BOOT BDM JTAG Tricore
MPPS V18
KESS v2
KTAG
FgTech 2 /
Fgtech 4
So, 3 options are available for OBDII connection: mpps v18, kess, fgtech
3 options for BOOT: kess v2, k-tag, fgtech galletto
2 options for BDM: ktag, fgtech
2 options for JATG: ktag, fgtech 4/2
Only 1 way for Tricore: MPPS V18!

That is why you need buy more than one ecu programmers.

Kess V2 V5.017 Red PCB Plus KTAG Red PCB V7.020

Kess V2 V5.017 Plus K-TAG Plus LED BDM Frame

Kess V2 Firmware V5.017 support online service, can work with interent, no tokens need, newly add 140+ protocols. And V7.020 KTM100 KTAG supports many encrypted new car models works I.E Toyota 76FXXX, PSA 17.4.4, Ford E83, VW 17.5.5 (1766), Mercedes-Benz 276ECU, Toyota 76F, etc.100+ ECU types added. LED works for 12V. After you connect with the probe, disconnect 12V battery for LED,it will works.The probe pin is adjustable.

KESS v2 V2.47 Plus V7.020 KTAG Plus BDM Probe Adapters Full Set with Free ECM TITANIUM V1.61

Best ECU Programmer Combination Kit for 12V Cars and 24V Trucks including Red PCB EU Version Kess V5.017, Red PCB EU Version Ktag V7.020, BDM Probe Adapters Full Set,Offer ECM TITANIUM V1.61 Download Link for Free.
